Full Control 530
5-Axis CNC Bridge Saw for Complete Slab Fabrication
by FLESSMART
Explore the Product
FLESSMART 530
It is not simply a bigger bridge saw.
It is a machine built around Full Control.
Full Control is the Control Anchor for the FLESSMART 530 — a 5-Axis CNC Bridge Saw built around one coordinated slab-fabrication workflow.
Start with the complete machine.
FLESSMART 530 is the current flagship 5-axis CNC bridge saw in the Slab Control product range. This page now stays with the physical product, its working evidence and its verified data.
Show the mechanism before describing the outcome.
The final launch story will pair every supported operation with the relevant setup, tooling, material condition and proof. Unverified operation names and performance figures remain outside the public copy.
One operation. One setup. One proof record.
Detailed motion ranges, supported operations and workflow descriptions will enter this page from the approved 530 product record. Until then, the machine view remains factual and visual.
Footage needs context.
This temporary reference clip marks the place for a verified 530 operation. Final footage will identify the operation, machine configuration, material and setup instead of relying on a generic cutting scene.
Approved 530 data, with conditions visible.
Only the public-approved F530-SPEC-001 through F530-SPEC-010 subset is shown here. Supported operations, application fit, service promises, media rights and unregistered performance claims remain hidden until separately approved.
Source: 02-DATA/products/530/product-fact-pack.md; claims F530-SPEC-001 through F530-SPEC-010. Complete pack remains draft_only; non-parameter claims stay hidden until separately approved.
Main motor 15 kW; pump 2.2 kW; stroke motor 1.5 kW; total 22.5 kW
Current production version; owner-confirmed parameter set.380/220/440 V; 60 Hz
Current production version; exact destination configuration must be confirmed per order.Ø350 mm; 3000 rpm
Do not infer an unlisted blade range or speed range.3200 × 2000 mm
Current production version.X 3200 mm; Y 2000 mm; Z 200 mm; A 0-90°; B 0-360°
Current production version.Workbench tilt 0-85°; cutting head 0-360°; chamfer rotation 0-90°
Current production version.60 mm
Material, blade and process conditions are not established.CAD programming; computer control; stated accuracy ±0.1 mm
Accuracy test method is not supplied and must not be inferred.5500 × 3300 × 2600 mm; 3.0 t
Installation clearance is not included.2 L/h
No test condition is registered; installation planning requires owner confirmation.See the 530 in your production context.
Request a demonstration, technical discussion or human-reviewed quotation conversation.
